Are You Really Using The Broadband Sander Correctly?

The wide belt sander not only fundamentally solves the technical problem of waterproof and dustproof of the lifting screw pair, but also greatly improves the stability; The wide belt sander ensures the synchronous lifting and lowering accuracy between two sets of lifting screw pairs, and greatly improves the service life. The sanding of plates must be standardized during operation.

Start up and working steps of wide belt sander

——  Adjust the thickness specification of sanding plate. For the mechanical lifting of the wide band sander, input the required sanding plate thickness on the touch screen, and the motor will automatically run to the set plate thickness. If there is a deviation between the sanding plate thickness and the set plate thickness, the thickness can be corrected on the touch screen; For hydraulic lifting wide band sander, the plate thickness can be set by changing the specification of the thickness gauge.

——  Connect the air source, the compressed air pressure reaches 0.6 MPa, and keep the air pressure of the broadband sander stable.

——  According to the sanding requirements of the wide belt sander, install the sand belt with the corresponding particle size, and adjust the swing frequency and swing amplitude if necessary. Wholesale price of Qingdao broadband sander manufacturers

——  Start each main motor of the wide band sander separately, and pay attention to starting in sequence. Only after one is fully started can the other wide band sander be started.

——  Start the dust removal system and brush roll motor of the wide belt sander.

——  Start the feed motor of the wide band sander and slowly adjust the speed to 5m/min.

——  The workpiece is sent to the wide band sander, and the thickness accuracy and surface roughness of the workpiece are tested after sanding. If necessary, re calibrate the coarse sanding roller, combined sanding frame and fine sanding frame until the sanding of the workpiece meets the requirements.

——  Feed the workpiece and gradually increase the speed of the wide band sander.
